Product Description

Bronze Ball Valve

Description

NETA Bronze Extra Heavy Globe Steam Stop Valve

  •  Screwed in Bonnet
  •  Inside Screw
  •  Rising Stem with Back Seat
  •  Renewable 13% Cr. Stainless Steel (ASTMA 182 Gr.F6a / AISI - 410) Trim
  •  Screwed Female Ends
  •  BSP Parallel Threads
  •  Handwheel Operated

Max. Working Pressure : 250 PSIG
Max. Working Temperature : 220°C
Test Pressure : 500 PSIG Hyd.

Suitable for steam and liquid service.



 P.No. Part N os.
 Material Specifications
 1 Nut 1 M.S. IS:1367
 2 Washer 1 M.S. IS:226
 3 Handwheel 1 C.I. IS:210 Gr.FG200
 4 Stem 1 13% Cr. S.S.
 ASTMA 182 Gr.F6a / AISI - 410
 5 Gland Nut
 1 Bronze IBR 282[a][IV] Gr.B
 6 Gland 1 Bronze  IBR 282[a][IV] Gr.B
 7 Packing - Graphited Asbestos
 -
 8 Bonnet 1 Bronze  IBR 282[a][IV] Gr.B
 9 Body 1 Bronze  IBR 282[a][IV] Gr.B
 10 Check Nut
 1 Bronze  IBR 282[a][IV] Gr.B
 11 Disc 1 13% Cr. S.S.  ASTMA 182 Gr.F6a / AISI - 410
 12 Body Seat Ring
 1 13% Cr. S.S.  ASTMA 182 Gr.F6a / AISI - 410
 13 Locking Washer
 1 18% Cr. S.S. AISI - 304
 14 Locking Device
 1 Brass Sheet
 -

 15

Set Screw
 1 Brass -

Nominal Size
 L + 1.5
 H App.
 T W App.
 8 83 120 1/4 80
 10 83 120 3/8 80
 15 83 120 1/2 80
 20 95 128 3/4 87
 25 111 138 1 100
 32 133.5 155 1.1/4 110
 40 148 185 1.1/2 120
 50 178 210 2 155
