Bronze Pressure Gauge Cock
Product Details:
X
Product Description
Bronze Pressure Gauge Cock
Description
NETA Bronze Pressure Gauge Cock
- Fitted with Pressure Gauge Coupling Nut and Tail Pipe
- Screwed BSP Parallel Female Threads
Max. Working Pressure : 250 PSIG
Max. Working Temperature : 220°C
Test Pressure : 500 PSIG Hyd.
Suitable for steam and water service.
| Part | Nos | Material | Specification |
| Plug | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Body | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Nut | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Washer | 1 | CAF | IS:2712 |
| Washer | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Spring Washer | 1 | Spring Steel | - |
| Nut | 1 | Brass | IS:6912 Gr.FLB |
| Union Nut | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Tail Pipe | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Nominal Size | L + 3 | H App. | W App. | T |
| 10 | 132 | 65 | 92 | 3/8 |
| 15 | 143 | 65 | 92 | 1/2 |
