Cast Iron Pilot Operated Pressure Reducing Valve
Product Details:
X
Product Description
Description
NETA Cast Iron Pilot Operated Pressure Reducing Valve
- With Phos. Bronze / Stainless Steel (AISI - 304 / AISI - 316) Diaphragm
- Lumina Body Seat Ring
- Stainless Steel (ASTMA 182 Gr.F6a / AISI - 410) Working Parts
- Flanged BS-10 Table 'F' Ends
- Max. Upstream Pressure : 13 Bar
- Max. Working Temperature : 220°C
- Test Pressure : 26 Bar Hyd.
- Outlet Pressure Range : 5 to 45 PSIG, 40 to 100 PSIG, 90 to 150 PSIG
Suitable for steam and air service.
| Part | Nos. | Material | Specification |
| Screw | 1 | M.S | IS: 226 |
| Locking nut | 1 | MS. | IS: 1367 |
| Spring housing | 1 | C.I | IBR 86 to 93 Gr.A |
| Spring top disc | 1 | M.S | IS: 226 |
| Pressure adjusting | 1 | Carbon steel | IS: 210 Gr. FG200 |
| Spring bottom disc | 1 | M.S | IS: 226 |
| Gasket | 1 | CAF | IS: 2712 |
| Side plug | 1 | M.S | IS: 226 |
| Pilot valve body | 1 | 13% Cr. S.S | ASTMA 182 Gr. F6s/ AISI-410 |
| Main valve return spring | 1 | Carbon steel | IBR 307 |
| Pilot valve spring | 1 | Bronze | IBR 282 [a][iv] Gr.B |
Dimension
| Nominal size | L ± 1.5 | H App |
| 25 | 165 | 208 |
| 40 | 201 | 260 |
| 50 | 218 | 260 |
