Stainless Steels Ball Valve
Product Details:
Product Description
Stainless Steels Ball Valve
Description
NETA Bronze Extra Heavy Globe Steam Stop Valve
- Screwed in Bonnet
- Inside Screw
- Rising Stem with Back Seat
- Renewable 13% Cr. Stainless Steel (ASTMA 182 Gr.F6a / AISI - 410) Trim
- Screwed Female Ends
- BSP Parallel Threads
- Handwheel Operated
Max. Working Pressure : 250 PSIG
Max. Working Temperature : 220°C
Test Pressure : 500 PSIG Hyd.
Suitable for steam and liquid service.
| Part | Nos. | Material | Specification |
| Nut | 1 | M.S | IS 1367 |
| Washer | 1 | M.S | IS 226 |
| Hand wheel | 1 | C.I | IS 210 Gr. FG200 |
| Stem | 1 | 13% Cr. S.S | ASTMA 182 Gr. F6a/ AISI-410 |
| Gland nut | 1 | Bronze | IBR 282 [a][iv] Gr. B |
| Gland | 1 | Bronze | IBR 282 [a][iv] Gr. B |
| Packing |
| Graphited asbestos | - |
| Bonnet | 1 | Bronze | IBR 282 [a][iv] Gr. B |
| Body | 1 | Bronze | IBR 282 [a][iv] Gr. B |
| Check nut | 1 | Bronze | IBR 282 [a][iv] Gr. B |
| Disc | 1 | 13% Cr. S.S | ASTMA 182 Gr. F6a/ AISI-410 |
| Body seat ring | 1 | 13% Cr. S.S | ASTMA 182 Gr. F6a/ AISI-410 |
| Locking washer | 1 | 18% Cr. S.S | AISI-304 |
| Locking device | 1 | Brass sheet |
|
| Set screw | 1 | Bronze |
|
| Nominal size | L ± 1.5 | H app. | T | W App |
| 8 | 83 | 120 | 1/4 | 80 |
| 10 | 83 | 120 | 3/8 | 80 |
| 15 | 83 | 120 | 1/2 | 80 |
| 20 | 95 | 128 | 3/4 | 87 |
| 25 | 111 | 138 | 1 | 100 |
| 32 | 133.5 | 155 | 1.1/4 | 110 |
| 40 | 148 | 185 | 1.1/2 | 120 |
| 50 | 178 | 210 | 2 | 155 |
