Bronze Spring Loaded Safety Valve
Product Details:
Product Description
Bronze Spring Loaded Safety Valve
Description
NETA Bronze Spring Loaded Ordinary Lift Safety Relief Valve
- Enclosed Discharge
- Screwed Male Inlet
- Female Outlet BSP Parallel Threads
Max. Working Pressure : 150 PSIG
Max. Working Temperature : 220°C
Test Pressure : 300 PSIG Hyd.
Suitable for steam service.
| Part | Nos | Material | Specification |
| Easing Lever Pin | 1 | 13% Cr. S.S. | ASTMA 182 Gr.F6a / AISI - 410 |
| Easing Lever | 1 | C.I. Bronze | IS:210 Gr.FG200 IBR 282[a][iv] Gr. B IBR 282[a][iv] Gr.B |
| Adjusting Screw | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Adjusting Screw Lodc Nut | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Stem | 1 | Brass 13% Cr. S.S. | IS:6912 IS:6912 Gr.Gr.FLB ASTMA 182 Gr.F6a/ AISI - 410 |
| Upper Spring Disc | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Spring | 1 | Carbon Steel S.S | IBR 307 AISI - 304 |
| Spring Chamber | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Lower Spring Disc | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Valve | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Regulating Ring | 1 | Bronze | IBR 282[a][iv] Gr.B |
