Bronze Sleeve Packed Water Level Gauge
Description
NETA Bronze Sleeve Packed Water Level Gauge
- Screwed Male Ends BSP Taper Threads
- Automatic Shut Off Device in the Water Arm
- Right Hand Operated
Max. BOP : 250 PSIG
Max. Working Temperature : 220°C
Test Pressure : 500 PSIG Hyd.
Suitable for steam and water service.
| Part | Nos | Material | Specification |
| Plug | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Gasket | 3 | CAF | IS:2712 |
| Upper Arm | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Cone | 2 | Rubber | - |
| Washer | 2 | Bronze | IBR 282[a][iv] Gr.B |
| Glass Tube | 1 | Glass | - |
| Nut | 2 | Bronze | IBR 282[a][iv] Gr.B |
| Lower Arm | 1 | Bronze | IBR 282[a][iv] Gr.B |
| Ball | 1 | 18/8% Cr./Ni S.S. | AISI - 304 |
| Sleeve | 3 | Moulded Asbestos | - |
| Stem | 3 | 18/8% Cr./Ni S.S. | ASTMA 182 Gr.F304 / AISI – 304 ASTMA 351 Gr.CF8 |
| Nominal Size | L + 1.5 | T |
| 15 (1/2) | 90 | 1/2 |
| 16 (5/8) | 130.5 | 5/8 |
| 20 (3/4) | 130.5 | 3/4 |
