Neta Cast Iron Wafer Type Butterfly Valve
Product Details:
X
Product Description
Description
Neta Cast Iron Wafer Type Butterfly Valve
- PN-16 Conforming to BS:5155 with SG Iron Disc
- Lever Operated Intergal Nitrile Rubber Lining
- End Details : Suitable inseration between flanges as per BS:10 Table D / E Class 125
- Max. Body Test Pressure : 348 PSIG Hyd.
- Seat Test Pressure : 232 PSIG Hyd.
- Max. Working Temperature : 80°C
| Part | Nos. | Material | Specification |
| Flow control level | 1 | M.S | IS 226 |
| Flow control level plate | 1 | M.S | IS: 226 |
| C- Sunk, screw & amp. nut | 2 | M.S | IS:1367 |
| Upper stem | 1 | M.S / S.S | IS:1367/ AISI -410 |
| Body | 1 | C.I. | IS:210 Gr. FG200 |
| Body seat ring | 1 | Nitrile lined rubber |
|
| Disc-stem locking screw |
| M.S | IS: 1367 |
| Disc | 1 | C.I / CF 8M | IS: 210 Gr. FG200/ ASTM-351 |
| Lower stem | 1 | 13% Cr. S.S | AISI-410 |
| Disc & amp; lower stem L | 1 | M.S | IS: 1367 |
| Packing ring | 1 | Synthetic rubber |
|
| Spring & amp; spring pin | 1 | Carbon spring steel |
|
Dimension
| Nominal size | A ± 2 | B ± 3 | C app. | D App |
| 40 | 33 | 71 | 120 | 214 |
| 50 | 43 | 75 | 139 | 214 |
| 65 | 46 | 83 | 150 | 214 |
| 80 | 46 | 92 | 160 | 214 |
| 100 | 52 | 105 | 178 | 240 |
| 125 | 56 | 123 | 189 | 268 |
| 150 | 56 | 143 | 211 | 268 |
| 200 | 60 | 170 | 292 | 300 |
