Cast Iron Horizontal Lift Check Valve
Product Details:
X
Product Description
Description
NETA Cast Iron Horizontal Lift Check Valve
- Right Angle Pattern
- BS:5153
- Bolted Cover
- 13% Cr. Stainless Steel (ASTMA 182 Gr.F6a / AISI - 410) Trim
- Flanged Ends to BS:4504 Part 1 Table 16 / 11 / DIN 2533 PN16
- Raised Face Drilled / Undrilled
- Body Test Pressure : 26 Kg/cm² Gauge Hyd.
- Seat Test Pressure : 16 Kg/cm² Gauge Hyd.
Suitable for water, steam, oil and vapour service.
| Part | Nos. | Material | Specification |
| Cover | 1 | C.I | IS: 210 Gr FG200 |
| Studs and nuts | To suit | M.S | IS: 1367 |
| Gasket | 1 | CAF | IS: 2712 |
| Body | 1 | C.I | IS: 210 Gr. FG200 |
| Disc | 1 | C.I | IS: 210 Gr. FG200 |
| Disc ring | 1 | 13% Cr. S.S | ASTMA 182 Gr. F6a/ AISI-410 |
| Body seat ring | 1 | 13% Cr. S.S | ASTMA 182 Gr. F6a/ AISI-410 |
| Disc guide | 1 | C.I | IS: 210 Gr. FG200 |
| Locking pin | 1 | M.S | IS: 226 |
Dimension
| Nominal size | L | H |
| 15 | 90 | 55 |
| 20 | 95 | 60 |
| 25 | 100 | 68 |
| 32 | 105 | 70 |
| 40 | 115 | 75 |
| 50 | 125 | 90 |
| 65 | 145 | 110 |
| 80 | 155 | 120 |
| 100 | 175 | 140 |
| 125 | 200 | 150 |
| 150 | 225 | 155 |
| 200 | 275 | 175 |
