Bronze Ball Valve
Product Details:
X
Product Description
Description
NETA Bronze Ball Valve
- Full Bore
- Two Piece Design with Stainless Steel (AISI - 410) Ball and Blow-out Proof Stem
- Teflon (PTFE) Body Seat Rings and Seals
- Lever Operated
- Flanged Ends to BS-10 Table 'D'
Test Pressure : 300 PSIG Hyd.
| Part | Nos. | Material | Specification |
| Stem | 1 | 13% Cr. S.S | ASTMA 182 Gr. F6a/ AISI-410 |
| Lever nut | 1 | Brass | IS: 6912 Gr. LTB2 |
| Lever | 1 | M.I | IS: 2108 Gr. BM290 |
| Gland | 1 | Brass | IS: 6912 Gr. FLB |
| Gland packing |
| Teflon | PTFE |
| Body seat ring | 2 | Teflon | PTFE |
| Ball | 1 | 13% Cr. S.S | ASTMA 182 Gr. F6a/ AISI-410 |
| Body | 1 | Gun metal | IS: 318 Gr. LTB2 |
| Gasket | 1 | CAF | IS: 2712 |
| Studs and nuts | 4 Each | M.S | IS: 1367 |
| Body connector | 1 | Gun metal | IS: 318 Gr. LTB2 |
Dimension
| Nominal size | L ± 1.5 | H App. | W App. |
| 15 | 79 | 70 | 158 |
| 20 | 81 | 80 | 158 |
| 25 | 95 | 85 | 178 |
| 32 | 104 | 85 | 170 |
| 40 | 114 | 95 | 210 |
| 50 | 127 | 100 | 225 |
